Horizontal steam boiler
Boiler
Environmental Protection Boiler
DZH new steam boiler for the home-style single-drum vertical tube shell boiler water and fire. Grate combustion equipment for activities. Left and right furnace water wall heating surface for the radiation, the two wings and drum flue pipe thread for the convection heating surface. Before and after the furnace wall and the outside wall on both sides of masonry from the use of refractory bricks.

Arch of the boiler tube plate, threaded pipe, such as technology, to solve the shell-and-pot boiler tube plate cracks, the lower drum drum kits, low thermal efficiency, coal poor adaptability.

2, the combustion process:

Fuel entering the combustion chamber in the grate, the flue gas production along the drum at the bottom of the wall, as there is in the interval I into the two wings of the tobacco control convection, through the box before the smoke pipe entered the thread, after ESP, drawn by the suction fan primer discharged into the atmosphere through the chimney.

3, the technical characteristics:

⑴, the use of arch tube-sheet composition with threaded pipe drum, so that quasi-steel drum by the change of body structure, whichever is the flexibility to remove the tube sheet of drawing up the pieces of the district to reduce the stress. Tube plate return pipe from the two re-return to solve the problem Tubesheet crack.

⑵, the lower drum riser as a result of the exclusive arrangement, the elimination of stagnant water at the bottom of the drum area, so that Java is not easy mud deposition, high temperature zone drum cooling would be good to prevent the lower part of the drum drum package.

⑶, the use of highly efficient heat pipe thread, was the effect of enhanced heat transfer to the boiler to heat up, step-up features quickly and improve the thermal efficiency of the boiler.

⑷, compact structure, compared with the same type of boiler, outside of their small size, investment in infrastructure to save the boiler room.

⑸, stable, easy to adjust, to contribute enough. With 110% overload capacity.

⑹, the use of threaded pipe enhanced heat transfer and improve the heat transfer coefficient and heat efficiency, flue gas in the tube due to perturbation effects are. Difficult breathing tube deposition, played the role of self-cleaning.

⑺, the eight-character wall furnace, window tobacco exports are certainly part of the role of dust. So that the original boiler emission control dust concentrations below standard, to ensure that dust emissions from the boiler to achieve the targets set by the State Environmental Protection.

4, the product manufactured:

The boiler is fully factory. Air blower, induced draft fan, dust collector, electric control units, pumps, valves, meters, smoke and other air duct to take over, matching the factory or by drawing the terms of the contract by the factory. Technical documents by the factory to provide a random list of two technical papers.
